* ROAD /RAILWAY TRANSPORTATION
cheapest, fastest.
*20/40HC CONTAINER
cheapest, fastest.
* RORO WESSEL
Cost higher than container, no disassembly required.
* BULK CARRIER
Cost higher than container, no disassembly required
* FLATBED SHIP
cost higher than container, no disassembly required.
* Others according to requirements
Price: $46300 USD for 1-3 items
Min.order : 1Unit
Manufacturer: Caterpillar
Year: 2021
Hours: 768
Bucket capacity: 1m³
Shipping : Sea freight/Land freight
This Excavator delivers power and performance in a compact size to help you work in the tightest applications. Its ability to fit through a narrow doorway makes it an excellent machine for indoor demolition work. Used excavators are more cost-effective.
Tonnage (tons) 20
Machine operating weight (kg) 20500
Bucket capacity (m³) 1.0
Boom length (mm) 5700
Arm length (mm) 2900
Performance
Swing speed (rpm) 11.3
Swing torque (Nm) 74.4k
Travel speed (km/h) 5.9
Bucket digging force (KN) 129
Arm digging force (KN) 99
Power system
Engine model Cat® C4.4
Rated power (kw/rpm) 110/2000
Displacement (L) 4.4
Cylinder bore × stroke (mm) 105*127
Emission standard National IV
Hydraulic system
Main pump maximum flow (I/min) 429
Working hydraulic oil circuit (Mpa) 35
Travel hydraulic circuit (Mpa) 34.3
Swing hydraulic circuit (Mpa) 25
Oil capacity
Fuel tank (L) 345
Hydraulic oil tank (L) 115
Hydraulic system (L) 234
Engine oil change volume (L) 15
Coolant (L) 25
Main transport dimensions
Total length for transport (mm) 9530
Total width for transport (mm) 2980/3170
Total height for transport (mm) 2960
Total length of crawler tracks (mm) 4450
Shoe width (mm) 600/700
Track gauge (mm) 2380
Minimum ground clearance (mm) 470
Counterweight ground clearance (mm) 1050
